AutoCAD Electrical Course Overview
This AutoCAD Electrical training in Madurai is designed to help students and professionals master electrical drafting and control system design. The course covers schematic drawings, PLC diagrams, wiring layouts, and project documentation. Through practical assignments and expert guidance, you’ll build the confidence to handle real-world electrical design tasks. With an ISO-approved certificate and career support, you’ll be ready for roles in automation, engineering, and manufacturing sectors.
Key Features
In-depth training focused on AutoCAD Electrical tools and workflows
Real-time practice with industry-based projects
Mentorship from trainers with professional experience
ISO-certified completion credential to enhance career growth
Career support, including portfolio building and placement guidance
The AutoCAD Electrical course you will Master
AutoCAD Electrical
Topics You will Learn
Module 1: Introduction to AutoCAD Electrical
- Understanding the AutoCAD Electrical interface
- Setting up and managing project files
- Drafting and editing electrical schematics
- Working with libraries and symbols
- Using standards and layers for designs
Module 2: Core Circuit Design
- Creating wiring diagrams and circuits
- Designing PLC input/output drawings
- Developing panel layouts
- Applying dimensions and annotations
- Using prebuilt libraries for faster design
- Customizing templates for projects
Module 3: Advanced Tools & Features
- Automatic wire numbering and tagging
- Managing cross-references in circuits
- Creating and editing project-wide BOMs
- Report generation and exporting formats
- Collaboration tools for team projects
- Error detection and troubleshooting methods
- Advanced cabinet and panel design
- Compliance with IEC/ANSI standards
Module 4: Practical Applications
- Designing industrial electrical circuits
- Drafting PLC automation schematics
- Electrical panel case studies
- Applying electrical codes and standards
- Documentation and report preparation
- Handling multi-user environments
- Presenting projects with accuracy
Module 5: Final Project & Career Portfolio
- Building a complete electrical project from start to finish
- Preparing detailed panel layouts
- Checking for design accuracy and validation
- Generating all project-related reports
- Finalizing documents for industry submission
- Creating a professional portfolio for job interviews
Let Your Certificate Speak
ISO-certified credentials on course completion
Project-based learning with circuit, PLC, and panel design
Career development support in automation and electrical design
After this course, you will be Able to
- Draft and edit accurate electrical schematics
- Create PLC and control panel documentation
- Generate BOMs and detailed project reports
- Apply electrical standards and codes effectively
- Build a professional portfolio for job opportunities
All You Need to Start this Course
Basic computer operation skills and interest in automation or electrical design. No prior AutoCAD knowledge required.
This is the One for You, If you are
Electrical engineering students aiming to master CAD tools
Freshers looking for entry-level roles in design/drafting
Professionals upgrading skills in CAD electrical design
Did You Know?
The average salary is
₹3.2L to ₹8L /year in India
Frequently Asked Questions
AutoCAD Electrical is built for electrical engineers to design control circuits, wiring systems, and panel layouts. It simplifies repetitive tasks such as numbering, tagging, and report generation, helping reduce design time and errors.
Yes, the course is beginner-friendly. It starts with the basics of the software before progressing to advanced tools. Even if you have no prior CAD knowledge, you’ll be guided step by step until you are confident.
The program usually takes around 2 to 3 months to complete, depending on batch schedules and project work. Flexible learning options such as weekend and fast-track classes are also available to suit your needs.
After completing the training, you can apply for roles like Electrical CAD Engineer, Design Engineer, and Panel Designer. Industries such as EPC, manufacturing, and automation frequently hire professionals with AutoCAD Electrical expertise.
By joining Madurai, you gain access to trainers with industry experience, practical project-based classes, and ISO-certified credentials. The added benefit of placement support ensures you’re job-ready upon completion.
